MB-2 10 GPM Hydraulic Valves
Specifications:

Max # Of Spools: 1

Max Operating Pressure: 3625 PSI

Max Back Pressure On Tank Port: 362 PSI

Fluid Temperature Range: -4  to 176 F

Ambient Temperature Range: -40 to 140 F

Operation: Manual Handle

Ports: SAE -8 (1/2" Female O-Ring)

Valve Type: Open Center
MANUAL HYDRAULIC VALVE
Part Number Example: MB-2-X-X-X


(1st "X") Relief Valve Code: 2= 580-1150 PSI, 3= 900-2900 PSI

(2nd "X") Spool Type Code: 1= Cylinders, 2= Motors

(3rd "X") Operator Code: 8= Spring Center, 61= Detent Both Ends,

The Numbers (1st "x") (2nd "x") & (3rd "x") Are The Variables In The Part # Above, The Rest
Remains The Same As Shown (Ex: MB-2-
3-1-8 would be a working part #)
Price With Any Option Listed:
$82.77
Most Valves Ship Same Day Or
Next Day, To Get Information To
Order Online Click
Here
MB-3 10 GPM Hydraulic Monoblock Valves
Specifications:

Max # Of Spools: 1-6

Max Operating Pressure: 4567 PSI

Max Back Pressure On Tank Port: 362 PSI

Fluid Temperature Range: -4  to 176 F

Ambient Temperature Range: -40 to 140 F

Operation: Manual Handle

Ports: SAE -8 (1/2" Female O-Ring)

Valve Type: Open Center

Circuit: Parallel

Power Beyond Capable (Plug Supplied)
Part Number Example: MB-3-X-X-X-X


(1st "X") # Of Spools Code: 3 Is 3 Spools etc. (1-6)

(2nd "X") Relief Valve Code: 2= 580-1150 PSI, 3= 900-2900 PSI

(3rd "X") Spool Type Code: 1= Cylinders, 2= Motors (Looking At Handle Side From Left To
Right, This "X" May Have Up To 6 Numbers, See Ex. Below)

(4th "X") Operator Code: 8= Spring Center, 61= Detent Both Ends

The Numbers (1st "x") (2nd "x") (3rd "x") & (4th "x") Are The Variables In The Part # Above,
The Rest Remains The Same As Shown (Ex: MB-3-
3-3-121-8 would be a working part #)
Price With Any Option Listed:
1 Spool:
$102.98
2 Spool: $151.70
3 Spool: $206.88
4 Spool: $258.74
5 Spool: $309.77
6 Spool: $361.72
Most Valves Ship Same Day Or
Next Day, To Get Information To
Order Online Click
Here
MANUAL HYDRAULIC VALVE
Specify Part # In Checkout
Specify Part # In Checkout
Specify part # in check out as described
below, after you enter your credit card
information.  "Add note to seller"
Youli Valves
If you have the full Youli
valve part # please
contact us for pricing.
If you have the full Youli
valve part # please
contact us for pricing.
