Honor Hydraulic Gear Pumps
|
Honor hydraulic gear pumps offer A356T6 pressure loaded
bearing blocks to provide smooth performance and high
efficiency. High temp Buna-N seals are rated up to 212
degrees F. This pump is a great choice for mobile and
industrial hydraulic applications. All pumps listed below have:
1/2" shaft x 1.51" long x 1/8" key, with "4F-17" 4 Bolt Mounting
Flange and 1.78" pilot, O-ring porting shown per each pump,
side porting. Chain or belt drive is not allowed. For use with
petroleum based hydraulic oils. Shaft rotation is determined
by viewing rotation from the shaft end of the hydraulic pump.
HONOR "4F-17" 4 BOLT FLANGE PUMPS
|
ITEM #
|
PART #
|
DISP/REV
|
FLOW@1750 RPM
|
PSI CONT.
|
PSI INT.
|
RPM RANGE
|
INLET PORT
|
OUTLET PORT
|
ROTATION
|
PRICE
|
6000
|
1AL1U01R
|
.08 CU IN
|
.6 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$124.97
|
6001
|
1AL1U01L
|
.08 CU IN
|
.6 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$124.97
|
6002
|
1AL1U02R
|
.12 CU IN
|
.92 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$124.97
|
6003
|
1AL1U02L
|
.12 CU IN
|
.92 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$124.97
|
6004
|
1AL1U27R
|
.16 CU IN
|
1.25 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$124.97
|
6005
|
1AL1U27L
|
.16 CU IN
|
1.25 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$124.97
|
|
6006
|
1AL1U35R
|
.21 CU IN
|
1.57 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$124.74
|
6007
|
1AL1U35L
|
.21 CU IN
|
1.57 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$124.74
|
6008
|
1AL1U04R
|
.25 CU IN
|
1.89 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$128.84
|
6009
|
1AL1U04L
|
.25 CU IN
|
1.89 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$128.84
|
6010
|
1AL1U05R
|
.31 CU IN
|
2.36 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$128.84
|
6011
|
1AL1U05L
|
.31 CU IN
|
2.36 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$128.84
|
6012
|
1AL1U06R
|
.37 CU IN
|
2.82 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CW
|
$131.22
|
|
6013
|
1AL1U06L
|
.37 CU IN
|
2.82 GPM
|
3000
|
3600
|
600-4000
|
3/4-16 (-8)
|
9/16-18 (-6)
|
CCW
|
$131.22
|
6014
|
1AL1U07R
|
.45 CU IN
|
3.42 GPM
|
2850
|
3300
|
600-2500
|
7/8-14 (-10)
|
3/4-16 (-8)
|
CW
|
$131.22
|
6015
|
1AL1U07L
|
.45 CU IN
|
3.42 GPM
|
2850
|
3300
|
600-2500
|
7/8-14 (-10)
|
3/4-16 (-8)
|
CCW
|
$131.22
|
6016
|
1AL1U09R
|
.55 CU IN
|
4.20 GPM
|
2550
|
2850
|
600-2500
|
7/8-14 (-10)
|
3/4-16 (-8)
|
CW
|
$133.23
|
6017
|
1AL1U09L
|
.55 CU IN
|
4.20 GPM
|
2559
|
2850
|
600-2500
|
7/8-14 (-10)
|
3/4-16 (-8)
|
CCW
|
$133.23
|
|
CLICK HERE FOR CONTACT INFO
Prices, Products and Availability subject to change at any time without notice.
|
Copyright © 2006 Twin Hydraulics, LLC. All rights reserved.
|
Most pumps ship same day!
|
CALL OR ORDER ONLINE!
Scroll Right For Pricing
ITEMS 6000-6009
ITEMS 6010-6017
Pay With Credit Card Or Paypal In Check-Out By Using The "Add To Cart" Buttons.
|
If you order a pump and it is not in
stock we will let you know right away
by e-mail or phone.
Please Call Or Email For UPS Next Day & 2ND Day Air Shipping Options
|
